How Filtering Node Works in Separated Environments¶

The application may be deployed to a few different environments: production, staging, testing, development, etc. These instructions provide information about suggested ways to manage a filter node for different environments.

What is an Environment¶

The definition of an environment may differ from company to company, and for the purpose of this instruction, the definition below is used.

An environment is an isolated set or subset of computing resources serving different purposes (like production, staging, testing, development, etc) and managed using the same or different set of policies (in terms of network/software configurations, software versions, monitoring, change management, etc) by the same or different teams (SRE, QA, Development, etc) of a company.

From the best practices perspective, it is recommended to keep the Wallarm nodes configuration synchronized across all environments used in a single product vertical (development, testing, staging and production stages).

Relevant Wallarm Features¶

There are three main features that allow you to manage different filter node configurations for different environments and perform a gradual rollout of filter node changes:

Resource identification
Separate Wallarm accounts and sub-accounts
Filter node operation mode

Resource Identification¶

There are two ways to configure the filter node for a particular environment using identification:

Wallarm unique IDs for each environment,
different URL domain names of environments (if it's already configured in your architecture).

Environment Identification by ID¶

The Applications concept allows you to assign different IDs to different protected environments, and manage filter node rules separately for each environment.

When configuring a filter node you can add Wallarm IDs for your environments using the Applications concept. To set up IDs:

Add environment names and its IDs in your Wallarm account → Settings → Applications section.
Specify ID configuration in a filter node:
- using the wallarm_application directive for Linux‑based, Kubernetes sidecar and Docker‑based deployments;
- using the nginx.ingress.kubernetes.io/wallarm-application annotation for Kubernetes NGINX Ingress controller deployments. Now, when creating a new filter node rule it is possible to specify that the rule will be assigned to a set of specific application IDs. Without the attribute, a new rule will be automatically applied to all protected resources in a Wallarm account.

Environment Identification by Domain¶

If every environment is using different URL domain names passed in the HOST HTTP request header then it is possible to use the domain names as unique identifiers of each environment.

To use the feature, please add proper HOST header pointer for each configured filter node rule. In the following example the rule will be triggered only for requests with the HOST header equal to dev.domain.com:

Separate Wallarm Accounts and Sub-accounts¶

One easy option to isolate the filter node configuration of different environments is to use separate Wallarm accounts for each environment or group of environments. This best practice is recommended by many cloud service vendors, including Amazon AWS.

To simplify the management of several Wallarm accounts, it is possible to create a logical master Wallarm account and assign other used Wallarm accounts as sub-accounts to the master account. This way a single set of console UI and API credentials can be used to manage all Wallarm accounts belonging to your organization.

To activate a master account and sub-accounts, please contact Wallarm's Technical Support team. The feature requires a separate Wallarm enterprise license.

Known limitations

All filtering nodes connected to the same Wallarm account will receive the same set of traffic filtration rules. You still can apply different rules for different applications by using proper application IDs or unique HTTP request headers.
If the filtering node decides to automatically block an IP address (for example, because of three or more detected attack vectors from the IP address) the system will block the IP for all applications in a Wallarm account.
